6ES7222-1BH32-0XB0 Digital Output Module for SIMATIC S7-1200

Digital Output Module 6ES7222-1BH32-0XB0 for S7-1200

The 6ES7222-1BH32-0XB0 digital output module is designed for seamless integration with Siemens SIMATIC S7-1200 systems. It offers 16 digital outputs with transistor switching, supporting 24 V DC and 0.5 A per output. This robust module operates reliably even in challenging environments, withstanding temperatures from -20 °C to +60 °C. Its compact design and high-quality construction make it ideal for industrial automation applications.

It fits perfectly into automation solutions where controllers based on SIMATIC architecture are deployed.

Technical specifications

• 16 digital outputs (24 V DC, 0.5 A each).
• Operating voltage range: 20.4–28.8 V DC.
• Typical power loss: 2.5 W.
• Output signal: „1” ≥ 20 V, „0” ≤ 0.1 V.
• Output grouping: single per group.
• Max output current per group: 8 A (horizontal installation).
• Cable length: up to 500 m (shielded), 150 m (unshielded).
• IP20 rated.
• Approx. weight: 220 g.
• Front connector required.

Key advantages

• Wide operating temperature range.
• Fast switching time (up to 50 µs).
• High reliability and quality.
• Certified: CE, UL, FM, Marine.

Applications and usage

The 6ES7222-1BH32-0XB0 module is ideal for industrial automation, manufacturing control systems, distributed I/O, and power distribution setups. It is suitable for both new installations and expansions of existing Siemens S7-1200 or simatic controller-based systems. Find more similar products in our Controllers category.
