Delivery: 20 working days.
6ES7331-1KF01-0AB0
SIMATIC S7-300 analog input module.
Price
223,00 €
Quantity
12 month warranty
Warranty on all
our products
Secure payment
Your data is
protected
Siemens 6ES7331-1KF01-0AB0 is an SM 331 analog input module designed for SIMATIC S7-300 automation systems. It provides eight isolated analog inputs for voltage, current, resistance and RTD measurements.
The module supports Pt100, Ni100, Ni1000 and LG-Ni1000 resistance thermometers, provides 13-bit resolution and a 66 ms module update time. It uses a 40-pin connector. The product is discontinued and has been replaced by 6ES7331-1KF02-0AB0.
Manufacturer: Siemens
Series: SIMATIC S7-300
Product family: SM 331
Product type: Analog input module
Article number: 6ES7331-1KF01-0AB0
Analog inputs: 8
Isolation: Yes, optical
Resolution: 13 bit
Measurement types: Voltage / Current / Resistance / RTD
Voltage ranges: 0–10 V, 1–5 V, ±1 V, ±5 V, ±10 V, ±50 mV, ±500 mV
Current ranges: 0–20 mA, 4–20 mA, ±20 mA
Resistance ranges: 0–600 Ω / 0–6000 Ω
Supported RTD: Pt100 / Ni100 / Ni1000 / LG-Ni1000
Module update time: 66 ms
Basic conversion time: 66 / 55 ms
Backplane bus supply: 5 V DC
Maximum current consumption: 90 mA
Typical power loss: 0.4 W
Maximum shielded cable length: 200 m
Connector: 1 x 40-pin
Net weight: 0.293 kg
Packaging dimensions: 13.20 x 15.20 x 5.10 cm
EAN: 4025515070467
Country of origin: Germany
Lifecycle status: Discontinued
End of product lifecycle: 2012-10-01
Successor: 6ES7331-1KF02-0AB0
