Delivery: 20 working days.
6ES7232-4HD32-0XB0
2-channel analog output module for S7-1200 PLCs, providing precise voltage and current signal output for industrial automation.
Price
297,96 €
Quantity
12 month warranty
Warranty on all
our products
Secure payment
Your data is
protected
| Siemens | Siemens |
|---|
Siemens 6ES7231-4HF32-0XB0 is an SM 1231 analog input module designed for SIMATIC S7-1200 automation systems. It provides 8 differential analog inputs for voltage and current measurement.
The module supports ±10 V, ±5 V, ±2.5 V, 0–20 mA and 4–20 mA signal ranges. It provides up to 12-bit + sign resolution, integrated diagnostics and configurable measurement smoothing.
Manufacturer: Siemens
Series: SIMATIC S7-1200
Model: SM 1231 AI 8×13 bit
Product type: Analog input module
Article number: 6ES7231-4HF32-0XB0
Analog inputs: 8
Input type: Voltage / Current
Input configuration: Differential
Voltage ranges: ±10 V / ±5 V / ±2.5 V
Current ranges: 0–20 mA / 4–20 mA
Resolution: 12 bit + sign
ADC resolution: 13 bit
Rated supply voltage: 24 V DC
Backplane bus current: Approx. 60 mA at 5 V DC
Maximum permissible input voltage: 35 V
Maximum permissible input current: 40 mA
Maximum cycle time: 625 µs
Diagnostics: Yes
Diagnostic alarm: Yes
Wire-break detection: Yes
Supply voltage monitoring: Yes
Measurement smoothing: Configurable
Protection rating: IP20
Operating temperature: -20°C to +60°C horizontal
Vertical operating temperature: -20°C to +50°C
Net weight: 0.187 kg
EAN: 6940408102040
UPC: 887621209841
Country of origin: Germany
Lifecycle status: Active Product
Product phase-out: From 2026-11-01
