6ES7223-1PL32-0XB0
S7-1200 digital I/O module with integrated inputs and outputs.
Price
190,48 €
Quantity
12 month warranty
Warranty on all
our products
Secure payment
Your data is
protected
Siemens 6ES7223-1PL32-0XB0 is an SM 1223 digital input/output module designed for SIMATIC S7-1200 automation systems. It provides 16 digital 24 V DC sink/source inputs and 16 relay outputs rated at up to 2 A.
The module is suitable for expanding the digital I/O capacity of compatible S7-1200 PLC systems. It features LED status indication and diagnostic functionality for industrial automation applications.
Manufacturer: Siemens
Series: SIMATIC S7-1200
Product family: SM 1223
Product type: Digital I/O module
Article number: 6ES7223-1PL32-0XB0
Module designation: SM 1223 DI 16x24V DC / DQ 16x Relay
Digital inputs: 16
Input voltage: 24 V DC
Input type: Sink / Source
Digital outputs: 16
Output type: Relay
Output current: 2 A
Relay output voltage: 5–30 V DC / 5–250 V AC
Supply voltage: 24 V DC
Permissible supply range: 20.4–28.8 V DC
Backplane current: Max. 180 mA at 5 V DC
Typical power loss: 10 W
Diagnostic alarm: Yes
Input/output status LEDs: Yes
Operating temperature: -20°C to +60°C horizontal
Width: 70 mm
Height: 100 mm
Depth: 75 mm
Weight: Approx. 350 g
EAN: 6940408102019
UPC: 887621206949
Country of origin: Germany
Lifecycle status: Active product*
