6ES7131-4BD01-0AB0
ET200S digital input module with 4 channels for distributed automation.
Price
259,43 €
Quantity
12 month warranty
Warranty on all
our products
Secure payment
Your data is
protected
| Siemens | Siemens |
|---|
Siemens 6ES7131-4BD01-0AB0 is a digital electronic input module designed for the SIMATIC ET 200S distributed I/O system. It provides four 24 V DC digital inputs for connecting switches, proximity sensors and other industrial field devices.
The module features configurable input delays of 0.1, 0.5, 3 or 15 ms, electronic sensor short-circuit protection and diagnostic functions with an SF group fault LED. It supports 2-wire sensors and provides electrical isolation between the digital inputs and backplane bus. The product has been discontinued since October 1, 2023 and is available as a spare part
Manufacturer: Siemens
Series: SIMATIC ET 200S
Product type: Digital input module
Article number: 6ES7131-4BD01-0AB0
Module type: 4DI High Feature
Digital inputs: 4
Rated input voltage: 24 V DC
Signal “0”: -30 to +5 V
Signal “1”: +11 to +30 V
Input current at signal “1”: Approx. 8 mA
Input characteristic: IEC 61131 Type 1
Configurable input delay: 0.1 / 0.5 / 3 / 15 ms
2-wire sensor support: Yes
Maximum sensor quiescent current: 1.5 mA
Sensor supply output current: 500 mA
Short-circuit protection: Yes, electronic
Diagnostics: Yes
Group fault indication: Red SF LED
Channel status indication: Green LED
Backplane bus current: Max. 10 mA at 3.3 V DC
Typical power loss: 0.7 W
Electrical isolation from backplane bus: Yes
Isolation test voltage: 500 V DC
Maximum shielded cable length: 1000 m
Maximum unshielded cable length: 600 m
Width: 15 mm
Height: 81 mm
Depth: 52 mm
Weight per module: Approx. 35 g
Packaging quantity: 5 modules
EAN: 4025515072577
UPC: 662643217698
Country of origin: China
Lifecycle status: Discontinued / Spare Part
Product cancellation date: 2023-10-01
