6ED1052-1FB08-0BA1
LOGO! 8 PLC controller with display, I/O and Ethernet.
Price
240,08 €
Quantity
12 month warranty
Warranty on all
our products
Secure payment
Your data is
protected
Siemens 6ED1052-1FB08-0BA1 is a LOGO! 230RCE programmable logic module designed for compact automation and control applications. It features an integrated display, 8 digital inputs and 4 relay outputs.
The module supports Ethernet communication, an integrated web server, data logging, user-defined web pages and standard microSD cards. It provides memory for up to 400 function blocks and can be expanded with additional LOGO! modules.
Manufacturer: Siemens
Series: LOGO! 8.3
Model: LOGO! 230RCE
Product type: Logic module
Article number: 6ED1052-1FB08-0BA1
Display: Yes
Digital inputs: 8
Digital outputs: 4
Output type: Relay
Supply voltage: 115/230 V AC/DC
Permissible AC range: 85–265 V AC
Permissible DC range: 100–253 V DC
Frequency: 47–63 Hz
Relay current: Up to 10 A resistive load
Program memory: 400 function blocks
Communication: Ethernet
Ethernet interfaces: 1
Integrated web server: Yes
Data logging: Yes
User-defined web pages: Yes
Cloud connectivity: Yes
Memory card: Standard microSD
Software: LOGO! Soft Comfort V8.3 or higher
Mounting: 35 mm DIN rail
Protection rating: IP20
Operating temperature: -20°C to +55°C
Storage temperature: -40°C to +70°C
Width: 71.5 mm
Height: 90 mm
Depth: 60 mm
Lifecycle status: Discontinued / Spare Part
Successor: 6ED1052-1FB08-0BA2
