Pepperl+Fuchs KFD2-STC5-Ex2 – SMART transmitter power supply

The Pepperl+Fuchs KFD2-STC5-Ex2 is a 2-channel intrinsically safe barrier designed for powering and interfacing SMART transmitters in hazardous areas. It supports both 2-wire and 3-wire transmitters, as well as SMART current sources, ensuring flexible integration into process automation systems.

The module safely transfers analog 4–20 mA signals to the control system while allowing bidirectional communication of digital protocols such as HART. It offers both current sink and source output modes, providing additional flexibility for different control system configurations.

Technical overview:
• Type: intrinsically safe barrier
• Channels: 2
• Input signal: 4–20 mA
• Output signal: 4–20 mA (sink/source)
• Supported protocols: HART, BRAIN, Foxboro
• Supply voltage: 18–30 V DC
• Output load: up to 600 Ω
• Accuracy: ≤ 10 µA
• Isolation: galvanic
• Mounting: DIN rail
• Operating temperature: –20°C to +60°C

Safety:
• SIL 2 (SC 3) acc. to IEC/EN 61508
• ATEX / IECEx certified
• Suitable for Zone 0, 1, 2

Typical applications:
• SMART transmitter integration (2-wire and 3-wire)
• Hazardous area signal transmission
• Process automation systems (PLC / DCS)
• Oil & gas and chemical industry

About the manufacturer:
Pepperl+Fuchs is a global leader in intrinsic safety and industrial automation solutions, specializing in explosion protection and process control technologies used worldwide.
