Allen-Bradley 1756-IF16 – analog input module

The Allen-Bradley 1756-IF16 is an analog input module designed for the ControlLogix platform, providing 16 input channels for accurate acquisition of voltage and current signals. It supports a wide range of industrial sensors and delivers reliable signal processing for precise monitoring and control in automation systems. The module is installed in a ControlLogix chassis and operates efficiently in industrial environments, typically within temperature ranges from 0°C to +60°C.

Technical overview:
• Series: ControlLogix
• Module type: analog input (AI)
• Number of channels: 16
• Input types: voltage and current
• Resolution: 16-bit
• Input ranges: 0–10V, ±10V, 0–20 mA, 4–20 mA
• Backplane current: approx. 100 mA @ 5V DC
• Operating temperature: 0°C to +60°C
• Mounting: ControlLogix chassis
• Protection rating: IP20

Typical applications:
• Process monitoring and measurement systems
• Temperature, pressure and flow monitoring
• Industrial automation systems
• Production lines
• Control cabinets

About the manufacturer:
Allen-Bradley, part of Rockwell Automation, is a global leader in industrial automation, known for reliable PLC systems, control components and advanced industrial solutions.
